SNL-LED (Snap N’Link)

QUICK OVERVIEW

RAB Design’s Snap n Link Series is an  easy to install,  LEGO-like modular design with flexible connectors that allow for effortless creation of eye-catching shapes and designs, all with a satisfying snap sound during installation.

• High quality, durable fixture with sturdy aluminum housing.
• Frosted polycarbonate lens that creates glare-free light distribution ideal for reflective and matt surfaces such as backsplashes, countertops, and in retail applications.
• Compact design and ultra slim profile – 0.65“ wide.
• Available in 3.3”, 10”, 20”, and 40” lengths.
• Button control switch is used to control light options.
Change the light setting through number of presses:
1st click = turn on light at 3000K
2nd click = change to 4000K
3rd click = change to 5000K
4th click = turn off light
Press and hold: increase/decrease brightness
• LEGO like modular design and flexible connectors allow for effortless creation of shapes and designs.
• Accessories include – vertical connectors (90°), angle connectors (80° – 280°), interconnect cables, and 4-way splitter cable.
• Vertical Connector (90) and angle connector (80° – 280°) emit light providing seamless continued illumination.

Note:

  • Hard wired and plug-in power supply options are available.
  • Flat and 45° mounting clips are included with each fixture.



Specification

Watts 1W
Lumens 85 Lm
Efficacy 85 Lm/W
Length 3.3"
Voltage 24VDC ( Plug in and Hardwire options available for 120VAC input)
CCT Colour Selectable (3000K/4000K/5000K)
CRI > 80
Dimming Touch button dimmer and TRIAC (hardwired drivers)
Total Harmonic Distortion (%) < 20%
Power Factor > 0.9
Beam Distribution 120°
LED Life (L70) > 36,000 hours
Housing Finish White
Lens Details Frosted PC Lens
Mounting Surface Mounted
Operating Temp. 0° to +45°C (32°F to 113°F)
Certifications cETLus (certified per UL 2108:2015 Ed 2 & CSA C22. 2#9.0)
