LFW-LED (NEW)
Linear Vapourproof LED
The LFW-LED is a ruggedly constructed fixture in a galvanized steel housing and tempered glass lens that is ideal to withstand exposure to corrosive substances such as dust, water, salt and cleaning agents.
FEATURES:
Rugged Construction
- Galvanized sheet metal housing and aluminum end caps helps to withstand corrosive ingredients such as dust, water, salt and cleaning agents.
- Tempered glass lens that provides high lumen transmittance and resistance for high temperature environments.
Functionality
- CCT Select Unit – Choose between 3000K/4000K/5000K using a switch that is located inside the fixture.
- High surge protection with additional 10kV standard offering along with built-in 2kV from driver.
- Optional Dimming PIR Motion sensor (factory installed).
- Chemical resistant polyester powder coat grey finish.
Easy to install
- Fixture can be through-wired leading to reduced installation time. Daisy chain up to 20 units for 40W and 10 units for 60W.
- 2 stainless steel mounting brackets that facilitate easy and quick surface mounting included in the box.
- Adjustable wall mount bracket, and pendant mount accessory available (order separately).
Specifications
| Input Power | 40W |
| Lumens | 6117 lm |
| Efficacy | 158.7 lm/W |
| Voltage | 120-347V |
| CCT | Colour Selectable (3000K/4000K*/5000K) |
| Surge Protection | 2kV Built-in Driver and Additional 10kV |
| CRI | 82 |
| Dimming | 0-10V Dim to Off |
| Total Harmonic Distortion | 8.06% |
| Power Factor | 0.998 |
| Beam Distribution | 106° |
| LED Life (L83) | 100,000 Hours |
| Housing Finish | Gray |
| Housing Details | Galvanized Sheet Metal |
| Lens Details | Clear Tempered Glass |
| Mounting | Surface (Ceiling/ Wall) Mount, Suspended Mount |
| Conduit Entries | 2 (1/2'' NPT) |
| Operating Temp. | -40°C to 40°C (-40°F to 104°F) at 120-277V -40°C to 35°C (-40°F to 95°F) at 347V |
| Factory Installed Options | PIR Motion Sensor |
| Options Sold Separately | Adjustable Wall Mount Bracket, Pendant Mount Accessory |
| Certifications | cULus Listed for Canada and USA, per UL1598, 5th Ed, NEMA 4X per UL 50E & NEMA 250, Wet Location, IP66, DLC Premium, 5 Year Warranty |
