XFL-LED
The XFL is the first floodlight in the market with field adjustable beam distribution, ensuring contractors get light exactly where they need it. Along with a host of
customizable features such as adjustable lumens and adjustable CCT, XFL family incorporates sturdy design built for extreme weather conditions. It is truly an innovation that gets the job done right the first time.
Selection Features
Over 100+ configurations in the box with selections for:
Universal Voltage:
- Fixture driver covers a wide voltage range of 120-347V.
Lumen Adjustment:
- Installer can select between 3 lumen settings using a lumen select switch located on the housing.
Colour Selection:
- Installer can select either 3000K or 4000K or 5000K colour temperature with a CCT select switch during installation.
Integrated Photocell:
- Fixture includes electronic photocell for XFL1 – XFL4 models and a twist lock photocell for XFL5-XFL6. Photocell can be turned off using a switch on the housing.
Two Mounting Options Included:
- XFL1 and XFL2 models include fixture with pre-installed knuckle and separate yoke & mounting plate in the box.
- XFL3, XFL4, XFL5, XFL6 models include fixture with pre-installed slip fitter and separate yoke in the box.
- The knuckle/slip fitter can be removed easily and be replaced by the yoke if needed. Mounting plate for knuckle mount installations included for added convenience.
Adjustable Beam Distribution:
- The beam distribution of the fixture can be easily adjusted on the job site by using a key (included, see install instructions for details).
- Fixture has 3 beam distribution settings: Extra Wide – 90° (NEMA 7×6), Wide – 75° (NEMA 6×6), Medium Wide – 55°(NEMA 5×5).
- Factory installed options for narrow beam distribution available.
Construction and Design:
- The XFL is available in 6 different sizes with a comprehensive range of lumen packages ranging from 2100lm – 75000lm.
- Robust construction with die cast aluminum housing and clear glass lens.
- Fixture is IP65 rated and has an operating temperature of -40° C to +50° C built to withstand cold Canadian weather.
- Fixture has an integrated visor shield that help to direct light, reducing unwanted glare.
- Standard finish is bronze. Custom finishes are available.
- Cable length of 0.5 metre for XFL1/XFL2 and 1 metre for XFL3/XFL4/XFL5/XFL6 for easy installation.
- Power factor >0.98 results in reduced power losses and an efficiency of 150 lumens per watt.
- High surge protection of 6kV internal and 10kV external for XFL3/XFL4/XFL5/XFL6.
Specifications
| Light Output | 5250/3750/2250 lm |
| Efficacy | 147 lm/W |
| CCT | CCT Selectable (3000K/4000K/5000K) |
| LED Lifetime (L80) | 110,000 Hrs |
| CRI | 84 |
| B-U-G | B2-U0-G0 |
| Beam Distribution | Standard: Field Adjustable [Extra Wide (90˚, 7x6), Wide (75˚, 6x6), Medium wide (55˚, 5x5)], Narrow (Factory Installed): Narrow (30°, 5x5) |
| Wattage | 35/25/15 W |
| Voltage | 120-347 V |
| Surge Protection | 2.5 kV |
| Power Factor | > 0.98 |
| THD | < 10% |
| Dimming | 0-10 V (0-100%) |
| Housing | Die Cast Aluminum |
| Lens | Clear Glass Lens |
| Paint Specs. | Weather and Corrosion Resistant Polyester Powder Coat Finish |
| Housing Finish | Bronze, Custom Finish |
| Mounting | Knuckle (pre-installed), Yoke & Mounting Plate (included in box) |
| Weight (with Mounting) | 1.2 kg (2.69lbs) |
| Cable Specs | Input Power - 0.5m Cabtire Cable (3x18 AWG), Dimming - 0.5m Cabtire Cable (2x18 AWG) |
| Ambient Operating Temperature | -40°C to +50°C (-40°F to +122°F) |
| Certifications | cULus certified as per UL1598 & CSA C22.2 NO.250.0:21, Wet Location, 7 Year Warranty, IP65, DLC Premium |
