SKYSELECT Post Top mountSKYSELECT Post Top mount

SKY2S-LED

QUICK OVERVIEW

The SKY2S-LED series are performance area light with selectable features ideal for a wide range of applications including commercial and retail parking lots, car dealerships, and roadway lighting.

Performance

  • Colour Selectable allowing the installer to choose between 3000K/4000K (CCT Selectable)/5000K.
  • Variety of beam distribution patterns to choose from- Symmetrical*, Wide Asymmetrical, Elliptical Horizontal, Elliptical Vertical

Electrical

  • Fixture driver covers a wide voltage range of 120-347V.
  • 10KV external surge suppressor.
  • Power factor of 0.95 and above resulting in reduced power losses and efficacy of 125 lm/W

Construction

  • Ruggedly designed with die cast aluminum housing and semi-frosted polycarbonate lens.
  • Weather and corrosion resistant polyester powder coat finish.
  • IP65 rated to protect against contact and against the ingress of dust.
  • Ambient operating temperature of -40℃ to 45℃ to withstand Canadian weather.

Mounting

  • 3 options available- Twin Arm (Post Top for 3″ Tenon), Direct Pole Mount, Surface Mount (Canopy/Garage)

Controls

  • 0-10V Dimming (Dim to Off), Twist lock Photocell, 3PIN, 7PIN, Microwave Motion Sensor, PCLS (Photocell, CCT, Lumen Select)

Specification

Light Output 10000/7500/5000 lm (Lumen Selectable)
Efficacy 125 lm/W
CCT 4000/5000K (CCT Selectable)*, 3000K
Beam Distribution Symmetrical* Wide Asymmetrical Elliptical Horizontal Elliptical Vertical
LED Lifetime (L70) >110,000 Hrs
B-U-G B4-U0-G3
CRI 80
Wattage 80/60/40W
Voltage 120-347V
Surge Protection 10kV External Standard as per UL1449
Power Factor 0.95
THD 6.8%
Supply Cord 600V, STW (5x18 AWG)
Housing Die-cast Aluminum
Lens Semi-frosted Polycarbonate
Ambient Operating Temperature -40℃ to 45℃
Mounting Twin Arm (Post Top for 3" Tenon), Direct Pole Mount, Surface Mount (Canopy/Garage)
Paint Finish Weather and corrosion resistant polyester powder coat finish
Certifications cETLus certified as per UL1598 & CSA C22.2 NO.250.0:21, DLC Premium
Controls 0-10V Dimming (Dim to Off), Twist lock Photocell, 3PIN, 7PIN, Microwave Motion Sensor,
