SKYBOL6-LED

QUICK OVERVIEW

Illuminate your world with confidence and style. SKYBOL is stylishly designed and engineered to perform. Compliment your project with superior architectural aesthetics and exceptional performance at a cost-effective price. You can have it all! Explore beauty in functionality with SKYBOL.

Performance

  • Colour Selectable allowing the installer to choose between 3000k/4000k/5000k
  • Lumen selectable: 3200lm, 2700lm, and 1900lm
  • 360° Beam Distribution
  • Increased LED Lifetime: (L80) >100,000 Hrs
  • CRI – 76
  • BUG Rating-B1-U1-G1

Electrical

  • 4kV (Built-in Driver) as per ANSI/C82.77-5-207

Construction

  • Polycarbonate lens.
  • IK10 rated to withstand mechanical impact.
  • IP65 rated to withstand water and dust ingress.

Controls

  • 0-10v dimming (5%-10%)
  • DC Dusk to Dawn Photocell

Specification

Light Output 3200/2700/1900 lm (Lumen Selectable)
Efficacy 139 lm/W
CCT 3000/4000/5000K (CCT Selectable)
Beam Distribution Type V - 360 Degree
LED Lifetime (L80) >100,000 Hrs
CRI 76
BUG Rating B1-U1-G1
Wattage 24/19/14W
Voltage 120-347V
Surge Protection 4kV (Built-in Driver) as per ANSI/C82.77-5-207
Power Factor >0.99
Ambient Operating Temperature -40℃ to 50℃
Housing Extruded aluminum shaft, Die cast base
Lens Polycarbonate
Height 42.3"
Shaft Diameter 6.3"
Bolt Circle Diameter 3.94"
Weight 15.1 lbs
Certifications cULus Listed for Canada and USA, per UL 1598, CSA C22.2 No. 250.0, IK10, IP65, DLC Premium
Controls 0-10V Dimming (5%-100%), DC Dusk to Dawn Photocell
Lumen Maintenance (80) 120,000 Hrs
