SKYBOL6-LED
Illuminate your world with confidence and style. SKYBOL is stylishly designed and engineered to perform. Compliment your project with superior architectural aesthetics and exceptional performance at a cost-effective price. You can have it all! Explore beauty in functionality with SKYBOL.
Performance
- Colour Selectable allowing the installer to choose between 3000k/4000k/5000k
- Lumen selectable: 3200lm, 2700lm, and 1900lm
- 360° Beam Distribution
- Increased LED Lifetime: (L80) >100,000 Hrs
- CRI – 76
- BUG Rating-B1-U1-G1
Electrical
- 4kV (Built-in Driver) as per ANSI/C82.77-5-207
Construction
- Polycarbonate lens.
- IK10 rated to withstand mechanical impact.
- IP65 rated to withstand water and dust ingress.
Controls
- 0-10v dimming (5%-10%)
- DC Dusk to Dawn Photocell
Specifications
| Light Output | 3200/2700/1900 lm (Lumen Selectable) |
| Efficacy | 139 lm/W |
| CCT | 3000/4000/5000K (CCT Selectable) |
| Beam Distribution | Type V - 360 Degree |
| LED Lifetime (L80) | >100,000 Hrs |
| CRI | 76 |
| BUG Rating | B1-U1-G1 |
| Wattage | 24/19/14W |
| Voltage | 120-347V |
| Surge Protection | 4kV (Built-in Driver) as per ANSI/C82.77-5-207 |
| Power Factor | >0.99 |
| Ambient Operating Temperature | -40℃ to 50℃ |
| Housing | Extruded aluminum shaft, Die cast base |
| Lens | Polycarbonate |
| Height | 42.3" |
| Shaft Diameter | 6.3" |
| Bolt Circle Diameter | 3.94" |
| Weight | 15.1 lbs |
| Certifications | cULus Listed for Canada and USA, per UL 1598, CSA C22.2 No. 250.0, IK10, IP65, DLC Premium |
| Controls | 0-10V Dimming (5%-100%), DC Dusk to Dawn Photocell |
| Lumen Maintenance (80) | 120,000 Hrs |
