DVAKS200CG
The DVAKS200CG is a versatile weather-proof series of fixtures that can be ceiling, wall, or pendant mounted. With a variety of RAB Design Globes to pick and choose from, this series is ideal for industrial and commercial applications
Features:
- Threaded, precision die-cast aluminum fitter with a silicone gasket between wiring box and the fitter.
- Porcelain medium base socket with nickel-plated screw shell.
- Clear glass with a threaded neck.
- Threaded die-cast aluminum guard with a set screw for locking guard in place.
- Replacement glass is GL200.
- Lamp not included.
Models Available:
- DVAKS200CG – Ceiling Mount
Specifications
| Box | Precision die cast aluminum with four 1/2” NPT plugs installed and one open 1/2” threaded conduit opening on the top. One brass ground screw installed. |
| Gasket | Silicone gasket between the wiring box and the fitter. |
| Fitter | Threaded Precision die cast aluminum with a silicone gasket. |
| Socket | Porcelain, medium base, 4KV pulse rated socket with a nickle-plated screw shell and a spring-loaded centre contact. |
| Globe | Clear glass threaded. Replacement glass part is GL200. |
| Guard | Threaded die cast aluminum with a set screw for locking the guard in place. |
| Hardware | All brass hardware. |
| Max Wattage | 300 watts. |
| Finish | Natural aluminum. |
| Lamp | Not included. |
| Approval | cULus for wet locations. |
