ECPL
Frameless design along with lumen selectable, CCT selectable and wide voltage features. These highly-efficient LED panels provide uniform light distribution, high performance, and low glare.
Features
- 3000/3500/4000/5000 (CCT Selectable).
- 120° Beam Angle.
- Power factor 0.96 results in reduced power losses and an efficacy of 125lm/W.
- 1kV Surge Protection (Built-in Driver) as per IEC/EN61000-4-5.
- Robust construction with die-formed steel.
- Mounting- Recessed in T-bar grid ceiling with integral earthquake clips. Surface mount and suspension mount cable kit sold separately.
Specifications
| Model | ECPL14-LED40A20 |
| Watts | Selectable from 40W, 30W, 20W |
| Lumens | 5000 Max |
| Efficacy | 125 |
| Voltage | 120-347V |
| CCT | Selectable from 3500K, 4000K, 5000K |
| Beam Angle | 120° |
| CRI | 82 |
| THD | 12% |
| Operating Temp | -20℃ to 40℃ (-4˚F to 104˚F) |
| Dimming | 0-10V (Dim to Off) |
| Finish Options | White |
| Mounting Options | Recessed in T-bar grid ceiling with integral earthquake clips Surface mount and suspension mount cable kit sold separately |
| Certifictions | cULus Listed for Canada and USA, per UL 1598 & CSA C22.2 No. 250.0 DLC Premium, IP20 |
| Warranty | 5 Years |
