LFY4-LED
Introducing our linear vapourproof LED fixture, designed for versatility and durability in demanding environments. With adjustable lumen and color temperature settings and wide voltage range ensures compatibility to suit application in industrial and commercial spaces. The fixture combines rugged construction and contractor friendly installation and advanced features to deliver reliable, tailored illumination.
Features:
Stainless Steel Clips
Housing designed to avoid clips failing. Also fewer clips required while maintaining NEMA 4X and IP66.
Wider Profile
4.6″ wide to cover Standard junction box.
Fewer Components
Reduce the number of pieces making it easier to install.
Offset Driver
Driver is offset from the center and comes with 1′ long input cable.
Perfect Flat Housing Back
Leaves no gap with mounting surface.
Straightforward Assembly
2 conduit entries at each end, and guide marks at the back for conduit entries.
Cover for CCT and Wattages Switches
Prevents accidental changes to settings.
Quick Disconnect
Detach housing and lens/LED board easily.
This product is not suitable for car washes. Please see our LFW-LED series for car wash applications.
Specifications
| Light Output | 6400/4300/2850 lm |
| Efficacy | 144 lm/W |
| CCT | CCT Selectable - 3500K/4000K/5000K |
| Beam Angle | 113° |
| CRI | 84 |
| Replaces Up To | 2 Lamp T8 |
| Wattage | 41/30/20 W |
| Voltage | 120-347 V |
| Surge Protection | 2kV (Built-in Driver) as per IEC/EN 61000-4-5 |
| Power Factor | >0.96 |
| THD | <17% |
| Dimming | 0-10V (10-100% Continuous Dimming, Dim to Off) |
| LED Life (L70) | > 100,000 Hrs |
| LED Driver Specs | cULus certified per UL 8750; complies to FCC Part 15, ANSI C63.4, Class B |
| Battery Backup | 8W Battery Back Up (Optional) |
| Multifunction Sensor | Dimming High Frequency Motion Sensor |
| Bluetooth Control Motion Sensor (BCMS) | Microwave Motion Sensor |
| Fixture Ambient Operating Temperature | -40°C to 40°C (-40°F to +104°F) |
| Finish | Grey |
